This product is manufactured and designed to be compatible or used with appliances, or for selected commercial/domestic applications.

• Mid-position spring return valve with 22mm fittings and 3 Amp switch (SPST)
• Supply voltage 240V AC
• Industry standard cable colours
• Manual override lever

This is a high quality compatible, alternative product. It is designed to provide you with an alternative working solution to the genuine original equivalent. This alternative choice is reflected in all our compatible parts and accessories offering you a cost saving against the original product. All manufacturers’ names and numbers used for reference purposes only.

Universal products can be used for many makes and models of machine providing it matches the product type and specification. We stock and supply a wide range of universal spare parts, consumables and accessories.

SPECIFICATIONS

• Supply voltage 240V. AC 50Hz
• Power consumption: 6W
• Operating temperature range: +5 to +88 °C
• Cable length one metre
• Max. differential pressure for 22mm = 1Bar
• Max. static pressure 10.0 Bar
• Max. ambient temperature 52 °C

INSTALLATION

Before fitting the valve, read through the plumbing and wiring instructions. When replacing the valve actuator only, set the Auto/Manual lever to the “Manual Open” position before removal. On the replacement actuator set the Auto/Manual lever to “Manual Open” position before fitting.

WIRING

• All wiring should be carried out to IEE Regulations
• White – Room Thermostat Call / Heating on
• Grey – Cylinder Thermostat Sat / Hot water off
• Orange – Cylinder Thermostat Call / Boiler and Pump
• Blue – Neutral
• Green & Yellow – Earth

PLUMBING

When connecting to pipe work do not use the actuator for leverage. Valves should be held by wrench flats on body. Place the AUTO/MAN lever in the MAN position when filling, venting or draining the system.

TAKE CARE NOT TO OVERTIGHTEN
